Plastic Recycling Washing Line Accessories
Label Remover
* Mechanically stripping offer lables from bottles instead of by water to save water.
* Label removing efficiency to 90-95%
* Add the protective net to the feed port to guarantee safe.
* Teeth type blades:Made by tungsten steel with copper welded using life will be twice.
Product Parameters
| Model |
Capacity(KG/H) |
Dimension(MM) | Power(KW) |
| LR500 |
500 |
4260(L)x2490(W)x3475(H) | 14 |
|
LR1000
| 1000 | 5475(L)x3122(W)x3680(H) | 20.5 |
|
LR2000
| 2000 | 6354(L)x3247(W)x3940(H) | 37.5 |
|
LR3000
| 3000 | 6123(L)x1600(W)x2865(H) | 55 |
Sink Float Tank
* Paddle speed control by inverter.
* Big angle design for tank.
* Special deisgn for drain screw and slag belt to lift sink impurities.
* Safety hood is equipped to ensure safety standard.
Product Parameters
| Model | Qty of Roller(Pcs) | Tank Width(MM) | Dimension(MM) | Power(KW) |
| SFW1200 | 4 | 1200 | 7200(L)x1580(W)x3680(H) | 6.05 |
| SFW1500 | 8 | 1500 | 8700(L)x1870(W)x3680(H) | 13.4 |
| SFW1800 | 8 | 1800 | 8700(L)x2200(W)x3680(H) | 15 |
Friction Washer
* Speed control device.
* Special design for blade of main shaft.
* Anti-wear steel for blade of main shaft.
* Self-cleaning device for mesh.
* Laser processes for mesh holes.
Product Parameters
| Model | Capacity(KG/H) | Dia of Rotor(MM) | Shaft Speed(RPM) | Power(KW) |
| FW-410 | 500-600 | 410 | 720 | 11/15 |
| FW-450 | 600-800 | 450 |
720
| 18.5/22 |
| FW-560 | 1000-1200 | 560 |
720
| 30 |
| FW-630 | 1500-2000 | 630 |
720
| 37 |
Centrifugal Dewatering Machine
* Heavy duty shaft, exchangeable blades with wear-resistant layers.
* Airpipe cleaning device.
* Special design for blade degree to meet different material.
* Three layers sealing prevents water from bearing.
Product Parameters
| Model | Capacity(KG/H) | Dia of Rotor(MM) | Width of Rotor(MM) | Power(KW) |
| HCD-400 | 300-500 | 400 | 1000 | 11/15 |
| HCD-540 | 1000-1500 | 540 | 1000 | 22/30 |
| HCD-660 | 2000-3000 | 660 | 1400 | 37/45 |
| HCD-900 | 800-1000/soft material | 910 | 1600 | 90 |
| HCD-1200 | 1000-1200/soft material | 1200 | 1600 | 110 |
Pre-Washer
* Low water consumption,95% recycled-release
* Simple water treatment.
* Active material washing processes.
* Self-cleaning device for tank wall.
Product Parameters
| Model | Capacity(KG/H) | Dia of Rotor (MM) | Shaft Speed (RPM) | Power(KW) |
| SW-1000 | 1000 | 580 | 760 | 45 |
| SW-2000 | 2000 | 750 | 760 | 65 |
Spray Washer(Cold Water & Hot Water)
* Equipped with water recycling system.
* More effective for hot water spray than cold water.
* The speed of screw is adjustable by inverter.
* Enforced spray could make impurities removing better.
Product Parameters
| Model | Installation Power(Kw) | Circulation Dose(M*/H) | Circulating Pump Power(KW) |
| SW800 | 7.5 | 20 | 4 |
| Rotor Diameter | Effective Working Length(MM) | Overall Dimension(MM) | Processing Capacity(KG/H) |
| Φ800 | 5500 | 7627(L)x4489(W)x2280(H) | 1000/2000/3000/5000 |
Screw Compactor
* Final product moisture will be 5-10%.
* New design for double-shaft disintegrator,low powerhigh capacity,
easy operation.
* Heavy duty gearbox and bearing parts to provide high torque import
Product Parameters
| Model | Capacity(KG/H) | Dia of Rotor(MM) | Motor power(KW) | Final Product Moisture |
| JG390 | 500-800 | 390 | 22 | 8% film |
| JG490 | 1000-1500 | 490 | 45 | 8% film |
Squeezer Machine
* Final product moisture will be 5-10%
* Heavy duty gearbox and bearing parts to provide high torque import.
* lt has the characteristics of high efficiency and energy saving.
* The equipment could replace the dehydrator and dryer in the whole cleaning production line.
Product Parameters
| Model | Capacity(KG/H) | Dia of Rotor(MM) | Final Product Moisture | Power(KW) |
| NG-320 | 550(PP)-750(PE) | 320 | 2-7%,semi-plasticization | 148.6 |
| NG-350 | 800-1000 | 350 | 2-7%,semi-plasticization | 176.6 |
Six-Channel Label Separator
* Add the bracket and hooks for convenient collection.
* Six channels separation ensures label separation rate >99.5%, dust <1%
* Unique "Z" structure design with dust filter.
* Material outlet is equipped with magnetic rack (as an option) to remove tiny magnetic metal.
* Screen can be equipped to subdivide flake size into 0-1.5mm, 3mm and 3-12mm.
Product Parameters
| Model | Capacity(KG/H) | Removal Lable Rate | Dimension(MM) | Power(kW) |
| LS1000 | 500-1000 | 15-20% | 1656(L)x1155(W)x5030(H) | 6.6/8.6 |
| LS2000 | 1000-2000 | 15-20% | 1656(L)x1155(W)x5030(H) | 8.6/14 |
| LS3000 | 3000-4000 | 15-20% | 1656(L)x1155(W)x5030(H) | 32.6 |
Trommel
* Function: remove stone, dust, loosen caps and small metal.
* Basis material: Galvanized carbon steel.
* Frame: Carbon steel.
Product Parameters
| Model | Dia of Barrel(MM) | Length(MM) | Motor Power(Kw) | Hole Dia(MM) | Basic Material of Beft |
| RMS1000 | 1000 | 4500 | 3 | 50 | PVC |
| RMS1500 | 1500 | 5000 | 5.5 | 50 | PVC |
| RMS1500 | 1500 | 6000 | 5.5 | 50 | PVC |
| RMS1800 | 1800 | 8000 | 7.5 | 50 | PVC |
